Strands FOR9T Dragon Drive XP
The current-generation FOR9T Dragon Drive combines Strands' distinctive no-edge styling with serious driving-light performance. Choose the compact 7" or full-size 9" version. Both include selectable white or amber position lighting, an illuminated Strands logo, E-approved E-mode and full-output Xperience mode.
- 7": 6,600 actual lumens in Xperience mode, 1 lux @ 446 m
- 9": 9,300 actual lumens in Xperience mode, 1 lux @ 600 m
- E-mode: 2,800 lm / 305 m (7") or 3,000 lm / 305 m (9")
- 6500K colour temperature
- White and amber position lights plus logo light
- 10-48V DC
- DT-4 connection with 550 mm cable
- IP67 aluminium housing with polycarbonate lens
- E-approved ECE R148/R149, Ref. 20; EMC ECE R10
- 3-year Strands function warranty
Sold individually. Wiring harness sold separately.
Choose Your Size
| Specification | 7" | 9" |
|---|---|---|
| SKU | 270967 | 270969 |
| Retail | $499 | $529 |
| Xperience mode | 105W / 6,600 lm / 446 m | 135W / 9,300 lm / 600 m |
| E-mode | 32W / 2,800 lm / 305 m | 30W / 3,000 lm / 305 m |
| Beam | Optimized / combo | Extended |
| Diameter | 180 mm | 220 mm |
| Depth | 91 mm | 90 mm |
| Height incl. bracket | 185 mm | 226 mm |
Wiring Accessories
- BrightSource Single-Light Wiring Harness 72999
- BrightSource Two-Light Wiring Harness 73240
- For three lights: Strands Siberia Pro High Power Harness Kit 270479
