Lazer Lamps · Toyota Tacoma grille lighting
Triple-R 750, built into the Tacoma.
Fit a pair of British-made Lazer driving lights into the factory grille of a 2020–2023 Toyota Tacoma TRD Sport or TRD Off-Road. This complete kit combines two Triple-R 750 lamps, Tacoma-specific mounts and the matching wiring harness. Choose Standard or Elite above.
Choose your kit
Standard or Elite?
Triple-R 750 Standard
A focused long-range beam with an integrated white position light.
$795 CAD $995
Complete kit SKU: GK-TAC-01K
Components in one complete kit- 2 × Triple-R 750 Gen 2 lamps with position light (00R4-G2-B)
- 1 × Tacoma grille mounting kit, including brackets, cutting guides and hardware (GM-TAC-01K)
- 1 × two-lamp, three-pin position-light wiring kit (2L-LP-PL-120)
Triple-R 750 Elite
More light and a wider beam in Boost mode, with the same Tacoma grille integration.
$995 CAD $1,195
Complete kit SKU: GK-TAC-ELITE-01K
Components in one complete kit- 2 × Triple-R 750 Elite Gen 2 lamps (00R4-G2-EL-B)
- 1 × Tacoma grille mounting kit, including brackets, cutting guides and hardware (GM-TAC-01K)
- 1 × two-lamp, two-pin wiring kit (2L-LP-120)
The GK number identifies the complete kit, whether supplied boxed or assembled from the genuine Lazer components above. The Standard has a white position light; the Elite does not. Select the correct kit before checkout.
The lights, compared
Compare Triple-R 750 Standard vs Elite specs
Manufacturer specifications for a pair of the Gen 2 lamps. Elite figures are in Boost mode.
| Two-lamp kit | Standard | Elite |
|---|---|---|
| Lamp part number | 2 × 00R4-G2-B | 2 × 00R4-G2-EL-B |
| Light output | 9,240 lumens | 10,136 lumens |
| Power consumption | 88 W | 104 W |
| Beam distance (1 lux) | 612 m | 679 m |
| Beam angle (horizontal × vertical) | 19° × 18° | 42° × 13° |
| Position light | White | No |
| Colour temperature | 5,000 K | 5,000 K |
| Operating voltage | 10–32 V DC | 10–32 V DC |
| Water resistance | IP68 | IP68 |
Beam distance is the manufacturer's two-lamp figure at 1 lux. Elite specifications are measured in Boost mode.
Purpose-built for the truck
Lighting that belongs in the grille.
Four vehicle-specific brackets position the lights within the original Tacoma grille. Included cutting guides and anti-theft fasteners help produce a secure, finished installation.
Fitment: Toyota Tacoma TRD Sport and TRD Off-Road, model years 2020–2023, with the applicable factory grille. Grille cutting is required. Check the grille and high-beam wiring configuration before installation.
The Cap-it Take
A clean Tacoma fit with real distance.
These are serious driving lights installed where they look at home. Choose Standard for its position light and focused beam, or Elite for a wider, higher-output beam. Save $200 on either complete kit while supplies last. Ask your local Cap-it about fitment and installation.
